Dimension / Size

A

B

C

D

E

UF-PVDF-1060

1874

1727

Ø250

Ø283

DN50(63mm)

Item

Specification

Model

UF-PVDF-1060

Dimension

Ø250  mm×1874 mm

Hollow Fiber Material

PVDF

Hollow Fiber ID/OD

0.7  mm/ 1.3 mm

Pore Size

0.03  μm

Surface Area (m²)

75  m²

Design Flowrate

3.0 - 6.0m³/hr

Design Flux

12  - 50 L/m².hr

Connection Size

Ø63mm (DN50)

Housing Material

UPVC

Sealing Material

Epoxy  resin & Polyurethane

Operation Temperature

5  ~ 50℃

pH

2  ~ 11

NaClO Resistance

2000  ppm

Max. Allowable Concentration of Free Chlorine

For Chemical Clean

5000  ppm

Max. Feed Water Pressure

0.3  Mpa

Max. TMP

0.2  Mpa

Bursting Pressure

>0.4  MPa

Operation Mode

Dead  End or Cross-flow Filtration

(Pressured Type Outside-to-In)

Max. Backwash Pressure

0.15  Mpa

Backwash Flux

100  ~ 150 L/H.m²

Air Scouring Flowrate Per Module

6  ~ 8 Nm³/H

Max. Air Scouring Pressurefor Backwash

0.1  Mpa

Backwash Time

30  ~ 60 seconds each time

Backwash Frequency

Every  20 ~ 60 minutes

Backwash Mode

Air  & Water Mixture Backwash

Removal of Bacteria

>6log

Removal of Escherichia Coli

>6log

* Permeate Turbidity

＜0.1 NTU

* Permeate SS

＜0.2 mg/L

* Permeate E.Coli

---

* Permeate SDI

＜ 3

* : take secondary (effluent)  discharge standard waste water as raw water for testing
